19mm Metal Switches(5A)
    19mm metal push button switch, can withstand current 10A, actuate at 5A/250VAC, the switch color can be customized according to the needs of the panel, and the EU/US certification is complete.

    Contact: *
    Company: MSN/skype:
    Subject:
    Tel: Fax:
    E-mail: * Website:
    Content: *
    Code: *(marked *should be filled)

    Description

    SPECIFICATIONS

    Panel Thickness: Ø19.20mm

    Contact Rating: lth 5A/250VAC  resistive load 3A/250VAC
    Mechanical Life: 200,000 cycles

    Electrical Life: 50,000 make-and-break cycles at full load

    Torque: 5~14Nm

    Travel: About 2.0mm

    Operation Pressure: 1.5±1N
    Contact Resistance: 50 mΩ max.
    Insulation Resistance: 100MΩ min.

    Dielectric Strength: 2,000 Vrms @sea level.
    Operating Temperature: -20°C to 85°C



    MATERIALS

    BUSHING : Stainless Steel / Nickel plated brass / Aluminum alloy

    BASE : PBT.

    ACTUATOR : Stainless Steel / Nickel plated brass / Aluminum alloy

    INNER ASSEMBLY : POM / PA66.

    SPRING : Spring steel.

    SEALING : Sillicone.

    O-Ring : Sillicone

    TERMINAL : Brass,with silver or gold plated.

    HEX NUT : Nickel plated brass
