1. RoHS compliant
2. Lead free
3. Dual color LED (Blue+Green) is available
Specification
POLE-POSITION : Momentary Type, SPST with LED
CONTACT RATING : 30V DC, 0.1A
CONTACT RESISTANCE : 50mΩ max. 1.5V DC; 100mA by Method of Voltage DROP.
INSULATION RESISTANCE : 100MΩ min. 500V DC.
DIELECTRIC STRENGTH : 500V AC for 1 Minute.
OPERATING FORCE : 250± 100gf.
OPERATING LIFE : 50, 000 cycles.
OPERATING TEMPERATURE RANGE : -40°C ~ 85°C.
TOTAL TRAVEL : 1.2± 0.3mm.
Materials
CAP : PC.
CASE & HOUSING : Nylon 6/6.
TERMINALS : Copper alloy with gold plated.
Applications
Computer servers/peripherals, Performance audio, Instrumentation, Telecommunications and Networking equipment.
