Panel Thickness: Ø30.20mm
Function:Momentary
Contact Rating: 50mA @ 12VDC.
Mechanical Life: 200,000 cycles
Electrical Life: 50,000 cycles make-and-break cycles.
Torque: 1~3Nm
Travel: About 0.3mm
Operation Pressure: About 1.5N
Contact Resistance: 50 mΩ max.
Insulation Resistance: 100MΩ min.
Dielectric Strength: 500 Vrms @sea level.
Operating Temperature: -20°C to 85°C
Ingress Protection: IP67
