Createn 6x6mm Tactile Push Button Switch with LED, Single/Two-Color, 4-Pin Round Button, Reset, Power Icon

Createn 6x6mm Tactile Push Button Switch with LED, Single/Two-Color, 4-Pin Round Button, Reset, Power Icon

Createn 6x6mm Tactile Push Button Switch with LED, Single/Two-Color, 4-Pin Round Button, Reset, Power Icon

1.RATING:12VDC 50mA
2.CONTACT RESISTANCE:100mΩ Max
3.INSULATION RESISTANCE: 250VDC FOR 1 MIN
4.DIELECTRIC STRENGTH:250VAC(50/60Hz)FOR 1MIN
5.LIFE TEST:100.000 CYCLES
6.0PERATION FORCE:250+50g

Description

6x6mm LED Illuminated Tactile Push Button Switch with Reue Light, 4-Pin Round Reset Power Button with Icon.png
