Ultra-thin tact switches

Tact Switches

SPECIFICATIONS

Feature: Vertical Push

Contact Rating: 50mA @ 12VDC.
Mechanical Life: 500,000 cycles

Electrical Life: 50,000 cycles

Contact Resistance: 100 mΩ max.
Insulation Resistance: 100MΩ min.100VDC

Dielectric Strength: 250 Vrms @sea level.
Operating Temperature: -30°C to +85°C



Features

※ Improve mounting density of components on PC board.

※ Reflow solderable

※ Sharp “click” feel with a positive tacile feedback

※ Packaged with a 12mm wide embossed taping.



Applications

※ Portable audio

※ Mobile phones and personal digital assistants

※ Operation of various digital devices








SPECIFICATIONS

Size: 5.2x5.2mm

Travel:  0.25±0.1mm

Operation Force: 70gf;90gf;130gf;180gf;250gf;320gf











SPECIFICATIONS

Size: 5.2x5.2mm

Travel:  0.25±0.1mm

Operation Force: 70gf;90gf;130gf;180gf;250gf;320gf;400gf;520gf;









SPECIFICATIONS

Size: 5.2X5.2mm

Travel:  0.25±0.1mm

Operation Force: 70gf;90gf;130gf;180gf;250gf;320gf;400gf;









SPECIFICATIONS

Size: 4.5x4.5mm

Travel:  0.2±0.1mm

Operation Force: 180gf;250gf;











SPECIFICATIONS

Size: 4.3x4.5mm

Travel:  0.2±0.1mm

Operation Force: 180gf;250gf;









SPECIFICATIONS

Size: 5.2X5.2mm

Travel:  0.15±0.1mm

Operation Force: 180gf;250gf;







SPECIFICATIONS

Size: 5.2X5.2mm

Travel:  0.15±0.1mm

Operation Force: 180gf;250gf













SPECIFICATIONS

Size: 5.2X5.2mm

Travel:  0.25±0.1mm

Operation Force: 70gf;90gf;130gf;180gf;250gf;320gf;









SPECIFICATIONS

Size: 4.8X4.8mm

Travel:  0.2±0.05mm

Operation Force: 180gf;250gf;
