6*6*4.3 waterproof SMT tactile switch

Createn 664.3 waterproof SMT tactile switch

Createn 664.3 waterproof SMT tactile switch

6*6*4.3

IP67 waterproof

Description

Operating temperature range：-30℃to+85℃

Rating：50mA.12V DC

Insulation resistance: 100MΩ min.100V DC

Dielectric strength: 250V AC for 1 min

Contact resistance: 100m Ω max.

Travel: 0.25±0.05mm

Operating fore:90gf/180gf /260gf/400gf

Life time:50000/100000/300000cycles

tact switch-2.jpg

undefined
